HH-90 Series Insulation Resistance Meter

HH-90 Series Insulation Resistance Meter
HH-90 Series Insulation Resistance Meter HH-90 Series Insulation Resistance Meter
Product Description
Specification
MODEL
HH-90/90E/90G
Standard
GB/T3048.5-2007
Range
10^5 ~ 2x10^14Ω
Rated voltage
100V, 250V, 500V, 1000V
Overall dimensions
280×240×105mm , HH-90G 320×290×115mm
Power supply
AC220V 50/60Hz 0.1A
Product Description
HH-90 Series Insulation Resistance Meter
Application:

Insulation resistance meter is an ideal instrument to test electrical insulating materials, wires and cables,
anti-static resistance measurements as well as other electrical products insulation resistance. Adopted the most
advanced international high resistance, micro current components , with advantages of high accuracy, strong
resolution, strong anti-interference ability, stable reading, small size, easy to carry and operate, and universal
battery. It is recommended by Shanghai Electric Cable Research Institute (SECRI) as one of the essential equipment
for production permit over the years
Standard:

GB/T3048.5-2007
Technical parameters:
* HH-90:
Rated voltage: 100V, 250V, 500V, 1000V
Range: 105 ~ 2x1014Ω
Applications: high insulation resistance measurement; electrical
appliances, electrical equipment, electrical equipment, wire and
cable insulation resistance measurement.
* HH-90E:
Rated voltage: 100V, 250V, 500V, 1000V
Range: 105 ~2x1016Ω
Applications: exceeding high insulation resistance measurement, common wire and cable and XLPE(Cross Linked
Polyethylene) cable measurements, insulation material resistivity measurement
* HH-90G:
Rated Voltage: 10V, 25V, 50V, 100V, 250V, 500V, 1000V
Range: 105~ 2x1017Ω
Applications: Exceeding high insulation resistance measurement, common wire and cable and XLPE(Cross Linked
Polyethylene) cable measurements, insulation material resistivity measurement. Weak current measurement,
measurement of electronic components, optical measurement, bio-power measurement, atomic energy research
* 31/2 digit display (with backlight), basic error: ± 1%, the built-in timer can be used to preset measuring time
* Companied with a electrode box, enable to be used as rubber & plastic surface resistance meter and volume
resistance meter (optional for users)
Specifications:
* Overall dimensions: 280×240×105mm , HH-90G 320×290×115mm
* Power supply: AC220V 50/60Hz 0.1A
