800 type RVS twist-free pair twisting machine:
Product and Vedio:
Application
Specially used for RVS two-core wire precision stranding, RVS wire full name copper-core
PVC insulation stranded connection with soft wire, twisted multi-stranded soft wire, mostly used in fire-fighting
systems, also called fire wire. Abbreviated twisted pair, commonly known as "flower line".
Speciification
|
Winding direction |
"S" or "Z" type arbitrary |
|
Screw distance |
20～100mm |
|
Screw speed |
the highest speed 1200R / min |
|
wire diameter |
8mm (Max) |
|
Wire speed |
10m/min-100m/min(Max) |
|
traction power |
2HP * 8P AC Shihlin motor + Blue Ocean Huateng inverter |
|
Applicable wire diameter range |
0.8-10mm |
|
Reel change time |
5-6 seconds |
|
Outside diameter |
200-460mm |
|
Inner diameter |
140-220mm |
